AMD 54” Max P1.5625 – Indoor LED Video Wall Display

AMD 54” Max P1.5625 Indoor LED Video Wall Display Solution

Forget about old video walls, we have an AMD 54” Max P1.5625 for you, which is a professional LED display. It is a massive, seamless 54-inch unit, which is the largest standard size in the industry. This screen is designed to make installation in control rooms and boardrooms feel almost as simple as mounting a big-screen TV. It is a 28mm ultra-thin screen that disappears against the wall. It also provides rock-solid performance for 24/7 operation in security, command, and broadcast environments.

We built this display to eliminate headaches. AMD 54” Max P1.5625 platform is capable of providing ruggedness of COB, the classic reliability of SMD, and advanced performance of IMD/MIP packaging. These things help to produce a perfect balance of image quality, durability, and budget. This screen has a pixel density of over 409,600 dots per square meter, which helps render with stunning clarity. The power consumption is low, which is around 180W/m², which means lower energy bills and less heat in your room. It also supports a long 100,000-hour lifetime. We focused on making it easy to install with standard VESA mounts and easy to trust for your most important applications.

Product Specification

• Pixel Pitch (mm) – P1.5625
• Pixel Density (dots/m²) – 409,600
• Cabinet Resolution (mm)(W×H) – 768×432
• Pixel Configuration – COB (SMD / IMD / MIP Optional)
• Cabinet Size (mm)(W×H×D) – 1200×675×28
• Brightness (nits) – 200~1000
• Gray Scale (bit) – 14~16
• Color Temp (K) – 2000~12000
• Control System – Synchronous control
• Frame Rate (Hz) – 60
• Refresh Rate (Hz) – 3840~7680
• Working Voltage (V) – AC: 110V~240V, 50~60Hz
• Max. Power Consumption (W/m²) – ≤450
• Avg. Power Consumption (W/m²) – ≤180
• Lifetime (H) – 100,000
• Operation Temp (°C) – -10~+40
• Storage Temp (°C) – -25~+60
• Operation Humidity (RH) – 10%~80%, no condensation
• Cabinet Weight (kg) – 17.5
