AMD V1.5 Series – Indoor LED Video Wall Display

AMD V1.5 Series – Ultra-Fine Indoor LED Video Wall Display Solution

If you are looking for a screen with a larger viewing distance, we have the AMD V1.5 Series LED Display. This display offers a 1.5mm pixel pitch and SMD LED technology. These features of this screen help it deliver clear, vibrant visuals across a wide range of professional indoor settings. You can use this screen in auditoriums, conference halls, retail spaces, hospitality venues, and command centers because it performs exceptionally well in all of them. You can also use it where you think screen size and visual impact matter more than ultra-close viewing clarity.

This screen features a slim 33mm cabinet and a 4.5kg panel weight, which makes installation easy. It also reduces structural requirements and on-site labor. The 16:9 panel format integrates seamlessly with standard HD, 4K, and 8K content. You can also install it in curved and corner spaces because it offers additional flexibility for unconventional areas.

This screen can handle fast-moving content and varied lighting conditions without flickering or washed-out visuals because it has a 3840Hz refresh rate and an 8000:1 contrast ratio. Front serviceability feature of this screen keeps maintenance accessible without disrupting surrounding structures or decor.

At an average power consumption of 105 W/m², it also runs efficiently compared to many displays in its category. Backed by a 100,000-hour LED lifespan and die-cast aluminum construction, the AMD V1.5 Series LED Display is a reliable, cost-effective solution built for long-term professional use.

Product Specification

• Model – AMD V1.5 Series
• Pixel Pitch (mm) – 1.5
• Pixel Density (dot/m²) – 409600
• LED Type – SMD
• Module Size W×H (mm) – 300*168.75
• Module Resolution W×H (pixel) – 192*108
• Panel Size W×H×D (mm) – 600*337.5*33
• Panel Resolution W×H (pixel) – 384*216
• Panel Material – Die-casting Aluminum
• Weight (Kg/pc) – 4.5
• Brightness (cd/m²) – 600
• Brightness Adjustment – Programmable/Automatic/Manual
• Viewing Angle (H/V) – 160°/160°
• Frame Rate (Hz) – 50/60
• Refresh Rate (Hz) – 3840
• Contrast Ratio – 8000:1
• Color Temperature (K) – 2000～10000 (Adjustable)
• Voltage (V) AC – 100-240
• Maximum Power Consumption (W/㎡) – 420
• Average Power Consumption (W/㎡) – 105
• Serviceability – Front
• IP Rating Front – IP30/Rear IP60
• LED Lifetime (Hours) – 100000
